Successfully Flashed Karbonn A1+ Latest Version

Vishal Jain · September 2, 2013 · 40 Comments

Karbonn A1+ was a good Android mobile phone in it’s range when it was launched. It was sold in a high quantity at the initial time of launching. But after some customer’s complaints and problems faced by customers at service centers, the selling of this phone is decreased suddenly. Anyways, this is not our concern. I got a Karbonn A1+ by redeeming some points I got by Airtel India as a retail partner. I purchased this phone, because there was not other good phone in the range of my currency points.

Read also: WhatsApp Will Now Let You Delete Sent Messages, But There is A Catch

I was eagerly waiting for that phone, as it was my first Android smart phone. I thought it would be a great phone according to its specifications displayed online. But when I got this phone in my hands, I became very disappointed. I just used this phone just for making calls for about 2 months. After that, I faced many problems in this phone. One day I thought to ROOT the phone. I searched over the internet, and found some tricks. During this, I bricked phone (My touch pad stopped working). I could not root this because there is still no working trick to root this phone. I give my phone to some senior mobile repairer professional to refurbish the phone’s software, because the touch stooped working due to some file corruption.Nobody could flash this phone. I myself also tried flashing this phone, but all in vain. There is a specific tool for Karbonn A1+ for flashing. We need the package fine for appropriate H/W and S/W version. My phones H/W version is 3.0.0 and S/W version is 2.0.7. As this was a new version, I was unable to get the flash files for this version also. Although I already downloaded the latest files which are version 2.0.8. I will be giving the links for all the required files at the end. As it is a Spredtrum based CPU phone, we have to modify the standard micro USB cable.

All we have to do is, open the CA101 cable, remove the black wire from it’s point and attach it to the only blank pin in the cable (There are total 4 wires in the cable and five pins in the socket). Refer the following diagram for modifying the cable:

Pre – Requirements for Flashing Karbonn A1+

  • Modified USB cable
  • Factory Download Tool For Karbonn A1+ (Links will be given at the end)
  • Packages File for appropriate H/W and S/W version (Links will be given at the end).

My mobile’s details are as below H/W version 3.0.0 S/W version 2.0.7 I could not find the appropriate files, so I have downloaded the latest version flash files (2.0.8)

Read also:

  • Get 1GB free 4G data on Airtel with a Missed Call
  • Airtel to offer free national roaming starting April 1st

Steps to Flash Karbonn A1+

  1. Open the FactoryDownload/UpgradeDownload tool.
  2. Select the *.pac file.
  3. Now go to setting and click on HWInfoImg file and select file with this name – XYL_XYL635143-1B_ILI9487_35_CMO_KMOEB_PZ286_DZTX_HW_info.
  4. Now click on start, connect the cable and immediately press the power key. If you do not immediately press the power key, it will not detect or you will get some other problem.
  5. Install the drivers provided with the tool. Do not install other drivers.
  6. Withing a few seconds, your phone will be flashed and it will shoe Passed.

I guarantee that you will not get success in the first attempt. So please pass your comments if you get any problem or do not understand how to do. Currently, I am unable to provide any screen shot. You can refer this thread http://forum.gsmhosting.com/vbb/f824/karbonn-a1-how-flash-hang-karbonn-mono-1591854/  for more information and screen shots. After flashing, you may face any or all of the following problem

  • White LCD
  • No Sound
  • Touch not working
  • Not Service (IMEI problem) CFT not callibrate.

To solve these problems, one by one change the HWInfoImg file in the folder bin>>HW_info>>PZ286_DZTX_HW_info>>KMOEB.

Download Links

  • Karbonn A1+ Latest Download Tool (With Drivers)
  • Karbonn A1+ Latest Flash Files ver 2.0.8 for new Hardware version (With All HWInfoImg files).
  • Extra Spreadtrum Drivers for Karbonn A1+.

I tried to include almost everything here, but if you do not find anything you are searching for, please push a comment. I will try to help you as soon as possible. I even faced many problems in facing this phone.

Main Keywords

  • How to flash Karbonn A1+
  • Karbonn A1+ touch not working
  • How to root Karbonn A1+
  • CFT does not calibrate in Karbonn A1+

Filed Under: Mobile Repairing

Comments

  1. ARAVINDH says

    November 18, 2013 at 10:13 pm

    i clicked start and connected cable and pressed power button
    but nothing happens

    Reply
  2. Jain says

    November 18, 2013 at 10:16 pm

    Did you modified the cable.?

    Reply
  3. ARAVINDH says

    November 24, 2013 at 10:32 pm

    how to modify the cable?
    please say

    Reply
  4. Jain says

    November 24, 2013 at 10:36 pm

    http://s24.postimg.org/tmq51pck5/images.jpg

    Reply
  5. ARAVINDH says

    November 27, 2013 at 5:16 pm

    whats that
    pls say eloborately in which i hav to change the wire?

    Reply
  6. Jain says

    November 27, 2013 at 5:20 pm

    Dude, there are total 5 pins and 4 wires in the Jack. Remove the black wire from it's place and attach it to the one which is blank.

    Reply
  7. MOHAMED SULAIMAN says

    December 29, 2013 at 11:46 pm

    Dude i ve oly 4 pins in the jack… wat shud i do??

    Reply
  8. Jain says

    December 29, 2013 at 11:48 pm

    Try another cable. In fact there are always 5 pins in a standard micro USB cable.

    Reply
  9. MOHAMED SULAIMAN says

    January 10, 2014 at 11:32 pm

    actually my hardware version and software versions are as follows
    H/W Ver: V4.0.0
    S/W Ver: V1.0.6

    wether can i use some other versions to flash my mobile??

    Reply
  10. Jain says

    January 14, 2014 at 10:20 pm

    You can download your required files from the following link
    http://support.moulnisky.com/index.php?dir=Karbonn/A1plus/Software%20Versions/

    Reply
  11. Anonymous says

    January 25, 2014 at 8:43 pm

    i couldnt root my karbonn a1+

    Reply
  12. Jain says

    January 25, 2014 at 8:45 pm

    Rooting of Karbonn A1+ is still not possible. Don't ever try, because I had almost bricked my phone.

    Reply
  13. Tahirv says

    January 26, 2014 at 10:31 pm

    u can successfully root ur karbon A1+ or duple using Kingo Android Root version 1.1.5 with ease

    Reply
  14. Afifah says

    January 27, 2014 at 9:01 pm

    where to get flash file for Karbon A1+ duple H/W 1.0 & S/W 1.0 version

    Reply
  15. Anonymous says

    February 5, 2014 at 7:55 pm

    U can root ur phone with root genius available in its official website

    Reply
  16. Anonymous says

    February 11, 2014 at 8:29 pm

    Press power key volume key and middle tech button at once these three keys together for 30 seconds or more to flash karbonn a1+ try its working…

    Reply
  17. rockey says

    February 12, 2014 at 8:55 pm

    how to check s/w h/w verson

    Reply
  18. Jain says

    February 12, 2014 at 8:57 pm

    It is written on the backside of the phone under the battery. Hope u will find it 😉

    Reply
  19. dinesh sharma says

    February 26, 2014 at 8:31 pm

    very veryy vveryy verryy greatt thankful to you sir

    Reply
  20. vinayak bhurke says

    February 28, 2014 at 4:27 pm

    can we install k a1plus duple files in k a1 plus i have both files by removing system.img with duple system.img

    Reply
  21. Jain says

    February 28, 2014 at 4:33 pm

    Though I have not tried, according to my other experience, I can only say it would not work. But if you have the backup of original files, you can give a try. Post your result if you do that.

    Reply
  22. akhtar hussain khan says

    March 9, 2014 at 10:31 pm

    in wich setting i have to go

    Reply
  23. akhtar hussain khan says

    March 9, 2014 at 10:31 pm

    sir can u explain in brief how to flash karbonn a1+
    plzz
    thankyou

    Reply
  24. VISHAL JAIN says

    March 9, 2014 at 10:37 pm

    Open the UpgradeDownload S/W. There are total 5 icons at top left. First is for loading the packet file (*.pac). The second is for the setting where you have to select the HWInfoImg file. Try again and post your result. Good Luck..!

    Reply
  25. akhtar hussain khan says

    March 16, 2014 at 4:05 pm

    phone gets restart evry tine thats y usb is geting unpuluging

    Reply
  26. akhtar hussain khan says

    March 16, 2014 at 4:05 pm

    did i have to press the pawor bttion till phone ghet start

    Reply
  27. Jain says

    March 16, 2014 at 4:08 pm

    Remove the battery and the cable from the phone. Now insert the battery. Now quickly insert the USB cable to the phone and press and hold the power key of phone. Make sure you have already clicked the Start button of the tool.

    Reply
  28. Manprit Singh says

    April 5, 2014 at 7:34 pm

    i have done all options of hw info then also it is showing problem of imei no. sir pls reply fast

    Reply
  29. Jain says

    April 5, 2014 at 7:37 pm

    Dial *#*#889988#*#* or Dial *#*#889933#*#* from your mobile and tell me what you are seeing there.

    Reply
  30. Sateesh Yadav says

    May 3, 2014 at 9:21 am

    I have karbonn a1+ its not detecting My Idea SIM Card (mobile network is not available) while same sim card is working fine on another any mobile. I have taken new sim card from Idea gallery this is also not working, And I have one another Vodafone sim card which is working properly. please help me to resolve my issue…..

    Thanks in advance..
    sateesh

    Reply
  31. Jain says

    May 3, 2014 at 9:29 am

    Try flashing the phone by following above steps. If it is under warranty, please go to service center once.

    Reply
  32. salman fahath says

    May 12, 2014 at 10:34 pm

    my phone start up dont work start and color visual appear contiously

    Reply
  33. Jain says

    May 12, 2014 at 10:37 pm

    Can u plz take a pic and post.?

    Reply
  34. akhtar hussain khan says

    July 24, 2014 at 10:37 pm

    did i have to push and hold the power buttion till my phone get on.. or have to rlerase it before.

    Reply
  35. akhtar hussain khan says

    July 24, 2014 at 10:37 pm

    how much time it takes to done ..

    Reply
  36. akhtar hussain khan says

    July 24, 2014 at 10:37 pm

    do i flash mywhen my phone is on…

    Reply
  37. Jitendra Kurdiya says

    August 6, 2014 at 9:26 pm

    karbonn a1+ imei change how to repair orignal imei n.

    Reply
  38. Anonymous says

    September 30, 2014 at 11:19 pm

    sir I have karbnn a1+ data cable yet I need to modify it.
    because this time I m trying upgrade download tool show wait ….
    for a long time

    Reply
  39. Anonymous says

    November 9, 2016 at 9:36 am

    link giving msg as file not found

    Reply
  40. VISHAL JAIN says

    November 9, 2016 at 9:48 am

    Thank you for letting me know. Will be updating the links soon.
